0.3w 1.8GHz RJ45 Face Recognition Attendance System

Name: 03w 18GHz RJ45 Face Recognition Attendance System
Brand: SCANMAX
Price: 1 USD

Buy cheap 0.3w 1.8GHz RJ45 Face Recognition Attendance System product

Brand Name : SCANMAX

Model Number : F2-FHS

Certification : CE, RoHS

Place of Origin : Shenzhen, Guangdong, China

MOQ : 1 pcs

Price : Negotiation

Payment Terms : Western Union, T/T, Paypal

Supply Ability : 200PCS/Week

Delivery Time : Within 5 working days after receiving the balance

Packaging Details : Normal craft paper and foam

CPU : Quad-core, 1.8GHz

storage capacity : RAM 2G ROM 8G

Operating temperature : -20℃～60℃

Working humidity : 20%~90% (non-condensing)

USB : USB 2.0

Ethernet port : RJ45

Contact Now

F2-FHS Android Face Recognition Attendance System with QR Code and IC Card

Features
*Dynamic detection, solve the deception of photos on various carriers
*Recognition Height:1.2-2.2m
*Recognition Distance:0.3-1.2m
*Detection Rate:1-2sec/person-time
*Precision:± 0.5 ℃
*Support external QR code scanner, ID card reader
*Support RS232 serial port, Wiegand 26 output, support configuration of output content
*Adopting dynamic face detection and tracking recognition algorithm based on video stream
*Support storage of 30,000 libraries locally；
*Fast recognition:
*(a)Face tracking and detection takes about 20ms
*(b)Face feature extraction takes about 200ms
*( c) The live detection face comparison takes 0.6ms (1000 people library, average value for multiple recognition), 0.8ms (10000 people library, average value for multiple recognition)
*Support public network and local area network
*Support HTTP interface connection;
*Support screen display content configuration, status display, custom content display, custom broadcast conten

F2-FHS Facial Recognition Temperature Measure Device Datasheet-EN
Product Specification with Infrared and RGB Camera

Face Recognition Temperature Measure all-in-one Machine
Product model		F2-FHS
Characteristics	Main function	Face recognition temperature measurement
	Use environmen	Indoor , semi-outdoor
	Color	Silver
Camera	Type	RGB	Infrared
	Resolution	2 million pixels	2 million pixels
	Aperture	F2.8	F2.8
	Focal length	3.18mm	3.18mm
	Software Dynamic	automatic	automatic
	Vertical wide angle	84°	84°
	Horizontal wide angle	54°	54°
	Infrared supplement light	Support
	White supplement light	Support
Core parameters	Android	Android7.1
	CPU	Quad-core, 1.8GHz
	storage capacity	RAM 2G ROM 8G
Human-comput er interaction	Monitor	8 inches, full viewing angle, 170 ° IPS LCD screen, resolution 800 * 1280
	Touch screen	support
	Face sensing module	support
	Face temperature measurement module	support,Serial / I2C interface
	Card reader	Support, Optional
Communication method	Ethernet	10/100 Ethernet
	WIFI	Comply with IEEE802.11b / g / n standard (2.4G)
Identification Method	Face	Support
	IC card	Support, optional
Input output interface	RJ45 interface	Support 10/100 Mbps
	Power supply interface	DC12V-2A
Power	Adapter	DC12V-2A
Environmental requirements	Operating temperature	-20℃～60℃
	Working humidity	20%~90% (non-condensing)
	Static protection level	IEC61000-4-2, LEVEL3
External Interface Definition
Type	Interface	Explanation
USB	USB 2.0	Support
Ethernet port	RJ45	10/100 Ethernet
Relay	NC COM NO	Relay normal off/Common/normal on.Usually,door lock supply is positively connected to the COM port,and then according to the door lock type,relay power negatively connected NO port or NC port. Note: Maximum load of relay contact is 2A
Gate sensor	IN GND	Check door open/close status, input
Exit button	PUSH1 GND	Press the button,door opening control signal,input
Serial	RX TX	RS232
Output power	5V GND	Support device external output 5V
Wiegand	WG_D1 WG_D0 GND	Wiegand output interface, support 26bit / 34bit protocol
Input power	GND 12V+	Power input:12V DC
Temperature measurement module	Operating temperature	0℃ ~ +55℃
	Storage temperature	-20℃ ~ +65℃
	Power consumption	< 0.3w
Basic Parameters	Pixel	32*32 Real-time temperature output
	Measurement accuracy	I + 0.5℃
	Measuring distance	0.3 ~ 1.0m
	WIFI	2.4G 802.11b/g/n
	Bluetooth	BluetooH4.0
