Auto Reading Barcode Scan Engine LV1000 TTL232 Interface Built in POS
Two-In-One Design: Seamless integration of imager and decoder board makes the scan engine small, lightweight and easy for integration.
Superior performance: The LV1000 barcode scanner module delivers fast and accurate reading of 1D barcodes.
Low power consumption: The scan engine provide san optimal solution for battery-operated equipments and mobile devices.
Easy to use: Simple parameter configuration.
Designed for OEM machines, easily embedded into all kinds of devices that need the 1D barcode reading application.
Technical Specifications of LV1000 1D Barcode Scan Engine
| Model | LV1000 |
| Interface | TTL232 |
| Image sensor | CCD |
| Scan rate | up to 200 scans/sec |
| Light source | LED (622 - 628nm) |
| Depth of scan field | 40-430mm |
| Illumination | 0-100,000 lux |
| Power consumption | 0.33W |
| Voltage | DC 3.3 V |
| Current | working: 150mA (maximum) Idle: 45mA Sleep: 1mA |
| Weight | 6g |
| Dimensions | 28x23x11mm |
Advantages:
- OEM develop special and small size
- 3.3-5V medical industry PC PDA
- Topside has electrical control parts, including flexible cable socket, interface socket, through which LV1000 barcode scanner interfaces with external device
- Aiming light, which sends rectangular, green light beam for aiming and illumination lights, which illuminates barcode
- Bracket covers sides and bottom of engine
- Two mounting holes on the bottom side are available for mounting engine to external device
- Back side is CCD circuit for image capture
Tool- Handy item for a task
Attention- Important subject to be aware of to avoid.
Tips- Helpful information about a topic or a feature.
Example- Illustration of how to use a feature.
Barcode Scanner FAQ
Q1: Can I get some samples? are they free?
A1: Of course, but samples are not free.
Q2: What's the delivery time?
A2: Depend on product and quantity of your order,sample could be sent to you in 3 work days after receiving balance.
Q3: What about payment?
A3: Payment terms: T/T,West Union and L/C etc.
Q4: Can you list the product of your company?
A4: Barcode Scanner Module, Desktop Barcode Scanner, Handheld Barcode Scanner, Portable Barcode Scanner Module, Bluetooth RFID Scanner, POS Terminal, Android Mainboard etc.
Q5: What's the OS of the POS?
A5: Android and Windows,details please refer to the technical data of the Product.
Q6: Where can we download the SDK/user manual for some of your products?
A6: SDK/User manual will be sent to you by email after the sample order.
Q7: Warranty time?
A7: 1 year
Q8: Do you provide Evaluation Kit for testing barcode scanner module?
A8: Yes, but you need to pay for EVK separately.
Q9: Product OEM?
A9: Yes, but it requiries the certain MOQ and the cost need to be added separately.
Q10: Customer service?
A10: Any questions of product after your receipt, please contact us,we'll reply you in 24 hours.
