1.75W QR Code Scanner Module USB Port 752× 480 CMOS Image Sensor
Safety Information
Precautions
1. Disassembly and retrofit
Do not disassemble or retrofit the device yourself. Artificial damages caused by failure to observe this precaution are not covered by the warranty.
2. External poer supply
Use only the supplied power adapter. Otherwise there is a risk of damage to the scanner.
3. Abnormal situation
Keep the scanner away from fire or heat sources. If there is unusual odor, overheating or smoke, immediately cut off the power and disconnect the power adapter. And contact your Rakinda Customer service center. Continued used in this case may result in fire or electric shock.
| Processor | IOTC 0370 CHIP |
| Interface | RS-232 (9.6~115.2Kbps) |
| USB 1.1(HID-KBW, HID-POS) |
| |
| Image Sensor | 752× 480 CMOS |
| | 2D: PDF417, Data Matrix, QR Code |
| | 1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, |
| | Codabar, Code 128, Code 93, ITF-6, ITF-14, |
| Symbologies | Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, |
| | Matrix 2 of 5, GS1 Databar (RSS-Expand, |
| | RSS-Limited, RSS-14), Code 39, Code 11, |
| | MSI-Plessey, Plessey |
| Scan Mode | Sense mode |
| Resolution | 10 mil |
| Light Source | White LED |
| Scan Window | 38.3mm*60.4mm |
| PCS | ≥30% |
| FOV | Diagonal: 85°, Horizontal: 63.7° , Vertical: 70° |
| Ambient Light | 0 ~ 100,000 LUX |
| Power Consumption | 1.75W (max.) |
| Power Adapter | Output: DC5V, 0.5A, Input: AC100~240V, 50~60Hz |
| Notification | Beep |
| Dimensions | 90mm(Diameter) x 60mm(H) |
| Weight | 300g |
| Operating Temperature | -10℃ to + 50 ℃ |
| Storage Temperature | -20℃ to + 60 ℃ |
| Humidity | 5% - 95%(non-condensing) |
| Certification | FCC Part15 Class B, CE EMC Class B |
Question 1: Can I get some samples? are they free?
Answer 1: Of course, but samples are not free.
Question 2: What's the delivery time?
Answer 2: Depend on product and quantity of your order,sample sent to you in 3 work days after you payment
Question 3: What about payment?
Answer 3: Payment terms: T/T,West Union and L/C etc.
Question 4: Can you list the product of your company?
Answer 4: Barcode Scanner Module, Bluetooth RFID Scanner, POS Terminal, Android Mainboard.
Question 5: What's the OS of the POS?
Answer 5: Android and Windows,details please refer to the technical data of the Product.
Question 6: Where can we download the SDK/user manual for some of your products?
Answer 6: SDK/User manual will be sent to you by email after the sample order.
Question 7: Warranty time?
Answer 7: 1 year
Question 8: Do you provide EVK for barcode scanner module?
Answer 8: Yes,but not free.
Question 9: Product OEM?
Answer 9: Yes, the cost need to be added separately.
Question 10: Customer service?
Answer10: Any questions of product after you receipt,please contact us,we'll reply you in 24 hours.
